our compact style double block & bleed valve is designed with an overall length in accordance with asme b16:10. the single piece body design reduces potential leak paths and allows weight and space to be kept to a minimum. available with either trunnion mounted ball or floating ball design and with both full and reduced bore sizes.

contact

compact dbb valve specifications:
pressure rating	asme class 150 to 2500, api 6a up to 5000 api
temperature range	-50 deg c to 200 deg c, high temperature option up to 315 deg c available
design standards	asme b16.10, asme b16.34, api 6d, asme viii, asme b16.5
firesafe standards	api 607, api6fa, iso 10497
seat materials	soft seats: devlon, peek, ptfe & metal seats: tungsten carbide and chrome carbide

amse b16.10 overall length

allows the replacement of single isolate ball valves with the increased safety of true double isolation, without the need for expensive pipework modifications.

single piece body

the single piece body with threaded end inserts provides the most compact overall length and reduces potential leak points to an absolute minimum.

full through bore

valves are available with full bore sizes in accordance with api 6d, ensuring maximum flow for increased production rates and allowing pigging of the pipe line.

non intrusive trunnion plate

the integral trunnion plate design reduces leak paths through the body.

multiple bleed valve options

various bleed valve options and connections are available in line with customer requirements.
