pjm rfid tags-ag尊龙凯时

发布时间：2016/10/09 pjm rfid sato 浏览次数：2498

one of the key advantages of sato vicinity’s pjm rfid systems is the ability to identify tags on items when multiple items are stacked, or closely located, even in the presence of liquids. this stacking feature is provided by pjm stacktags®. we provide a number of tag formats and tag sizes to suit different applications.

the tag reference table details a number of popular tag types available from sato vicinity. depending on volumes, new tags can be designed for particular applications. typically, tags are provided as bare inlets, transparent adhesive labels or paper adhesive labels.

联系咨询

features

operation frequency 13.56 mhz

identification speeds up to 1200 tags/second (not including reader overhead)

command data rate of 424 kbit/s

reply data rate of 106 kbit/s per reply channel - reply data rate of 424 kbit/s can be used for single tag operation

reply frequency hopping over 8 randomly selected channels

rewritable eeprom, up to 8kbit of user memory

unique serial number

permanent write locking of user memory

optional 48 bit password protection

state retention during temporary power loss

minimal tag to tag stacking separation for large stacks

esd protection 2kv

eeprom data retention greater than 10 years

eeprom endurance greater than 100,000 erase/write cycles

fast eeprom programming



note

at manufacture, the st chip configuration word (word 6 in memory) is typically set to 6000hex for ease of manufacture and tag issuing/personalisation. when st chips are used in stacking applications the user must configure the chip by writing to the configuration word and changing its contents to 3000hex. for ease of chip configuration the user can configure the chips to 3000hex for all stacking or non-stacking applications.
