floating ball compact style-ag尊龙凯时

issue date：2006/01/26 oliver twinsafe dbb valves page views：1522

our compact style double block & bleed valves are designed with an overall length in accordance with asme b16:10. the single piece body design reduces potential leak paths and allows weight and space to be kept to a minimum. available with both full and reduced bore sizes.

contact

overview



available in amse b16.10 standard length (csl) up to 3" asme class 600 full bore

also available to oliver standard lengths (cosl)
floating ball design from 1" up to 3" class 600.
studded flanged pipeline connections in accordance with asme b16.5
integral vent valve with both threaded and flanged connections available



specifications



floating compact csl specifications
pressure rating 1" to 2" asme class 150 to 2500, 3" up to class 600
temperature range -50 deg c to 200 deg c, high temperature option up to 315 deg c available
design standards asme b16.10, asme b16.34, api 6d, asme viii, asme b16.5
firesafe standards api 607, api6fa, iso 10497
seat materials soft seats: peek, ptfe & metal seats: tungsten carbide and chrome carbide



product features



amse b16.10 overall length

allows the replacement of single isolate ball valves with the increased safety of true double isolation, without the need for expensive pipework modifications

single piece body

the single piece body with threaded end inserts provides the most compact overall length and reduces potential leak points to an absolute minimum.

full through bore

valves are available with full bore sizes in accordance with api 6d, ensuring maximum flow for increased production rates and accuracy of level measurements.

multiple bleed valve options

various bleed valve options and connections are available in line with customer requirements.
