shuttle xp 1000 robust solution for handling big loads-ag尊龙凯时

issue date:2016/10/11 kardex vertical lift systems page views:1134

the shuttle xp 1000 is especially suitable for use with big loads. each of its heavy-duty trays can handle loads weighing up to 1,000 kg and measuring up to 4.05 meters across. as such, this storage lift is ideal for picking medium-heavy to heavy parts and sets new standards in storage logistics in terms of load-bearing capacity. its efficiency can be further increased when handling heavy loads by integrating the optionally available hoisting crane or a mechanism for picking up entire pallets.

technical data

shuttle xp 1000
width 1,580 mm to 4,380 mm
depth   2,362 mm to 4,343 mm
height 2,550 mm to 20,050 mm
unit height pitch   100 mm increments
performance data
vertical speed

each tray individually adjustable

up to 0.75 m/s

total load   max. 67/120 t
trays
depth   610 mm to 1,778 mm
width/load per tray 1,250 mm 1,000 kg
  2,450 mm 900 kg
  4,050 mm 800 kg
all intermediate sizes possible at 50 mm intervals
