diversion ball valves-ag尊龙凯时

issue date：2006/01/26 ball valves oliver page views：1445

our diversion ball valves are designed for safely diverting flow to one of the two outlet ports. totally enclosed soft seats offer both positive sealing and low operating torques, from vacuum to high-pressure service. an anti-blow out spindle is fitted as standard with the ptfe spindle and body seals. we offer both bottom entry and side entry diversion ball valves.

contact

overview

the 'b6sl' type 3 way flow diverting ball valve is designed for safely diverting flow to one of the two outlet ports. totally enclosed soft seats offer both positive sealing and low operating torques, from vacuum to highservice. anti-blow out spindle is fitted as standard with the ptfe spindle and body seals.

note: firesafe option not available.

3d models are available upon request.

specifications

diversion ball valve specifications:
bore size 10mm only.
flow type 3-way
psi ratings up to 10,000 psi
firesafe? firesafe option not available.

product features

key features of our diversion ball valves:

totally enclosed soft seats giving positive sealing and low torque operation across the pressure range

one-piece spindle with anti-blowout shoulder that maintains seal integrity at all pressures

precision-machined ball for smooth operation through 180 degrees with 10mm 'l' pattern bore

ptfe spindle and body seals to give high body integrity

316 stainless steel one-piece handle fitted with twin anti-vibration locknuts
