our instrument double block and bleed (dbb) valves are suitable for pressures up to 6,000 psi, with a standard maximum temperature rating of 240 c. however, our in type instrument double block and bleed (dbb) valves are capable of withstanding temperatures up to 540 c as an additional option.

in type - maximum pressure 6,000psi (10,000psi available as an option). maximum temperature 240c (540c available as an option). comes with ptfe seals and contains a metal to metal seated needle valve. heavy duty firesafe versions are available.

id type - maximum pressure 6,000psi (10,000psi available as an option). maximum temperature 200c (240c available as an option). comes with a metal to metal seated needle valve and soft seated ball valve. ideal for double block and bleed for an instrument.

l type - maximum pressure 6000psi, maximum temperature 200c and contains a soft seated ball valve. ball valve bore size 10mm, 14mm and 20mm. ideal for injection, sampling and double block and bleed for an instrument.

t type - maximum pressure 6000psi, maximum temperature 200c and contains a soft seated ball valve. ball valve bore size 10mm & 14mm. ideal for compact injection, sampling and double block and bleed for an instrument.

3d models are available upon request.
