issue date：2016/10/13 xerafy xerafy rfid page views：1615

micro^x ii paint shop version is built to perform under extreme heat and repeated exposure to caustic fluids for applications such as autoclaves, hot water wash cycles and post-paint processes and is currently being used to track the skids that carry car bodies through the paint process. the tag can survive application temperatures of up to 250º celsius, has an ip68 rating and a read range of up to 10 meters.

contact

operating temperature	-40°f to 185°f (-40°c to 85°c)
compliance	rohs, ce, atex
ip classification	ip68
attachment	screws (rivet hole, m3), pop rivets (3mm), welding
peak temperature	482°f / 250°c 6 hours duration
temperature cycling test	30 minutes at 250°c; 1 hour cool-down; 600 test cycles
application temperature	-40°f to 482°f (-40°c to 250°c)
weight	0.98 oz (28 g)
read range on metal (2w erp)	up to 33 ft (10 m)
dimensions/tolerance (in)	2.01 x 1.43 x 0.30 ( /- 0.02)
dimensions/tolerance (mm)	51 x 36.3 x 7.5 ( /- 0.5 mm)
