roswell – autoclavable version-ag尊龙凯时

issue date:2016/10/13 xerafy xerafy rfid page views:1077

roswell, the first tag of its kind, uses only its stainless steel interior as an antenna. the patent-pending tag is constructed of two cylindrical metal cases with a thin high temperature substrate between them. while existing products in the market may use a tag packaged inside a metal case, roswell is completely different. because there is no rfid tag packaged inside roswell, the antenna-free design ensures reliability and durability by eliminating the risk of tag failure from high temperature and high pressure autoclave and corrosive liquids. roswell is designed for quick an convenient attachment and can be welded directly to metal trays or easily attached via a stainless steel bracket to a medical equipment.

description

compliance fda class i, rohs, ce
material stainless steel
ip classification ip69k
attachment welding, cable tie, rivet hole ø 0.19 in (ø 5 mm)
operating temperature -40°f to 185°f (-40°c to 85°c)
application temperature -40°f to 482°f (-40°c to 250°c)
read range on metal (2w erp) up to 16.4 ft (5 m)
weight / tolerance (w/o bracket) 0.92 oz / 26 g ( /- 10%)
weight / tolerance 1.55 oz / 44 g ( /- 10%)
dimensions w/o bracket/ tolerance (mm) ø 28 x 11 ( /- 0.5)
dimensions w/o bracket/ tolerance (in) ø 1.10 x 0.43 ( /- 0.02)
dimensions/tolerance (in) 1.89 x 1.10 x 0.53 ( /- 0.02)
dimensions/tolerance (mm) 48 x 28 x 13.5 ( /- 0.5)

specialties

withstands repeated autoclave cycles

resistant to chemical cleaning process

designed to meet fda requirements

180 degree read orientation



applications

autoclavable surgical trays

medical devices
