jet steam trap-ag尊龙凯时
issue date：2016/10/13 steam traps page views：1106
application
multi-stage pressure systems
condensate systems with no draining rock bottom
function
pressure drops over the nozzle length cause flash steam and a necking of the outlet
at no-load operating an enlargement of the steam capacity causes the necking
design features
low wear and trouble-free
insensitive to dirt
automatic condensate discharge when system is switched off
variable mounting positions
venting
ideal for venting steam spaces
automatic start-up and continuous bleeding when using as a steam trap
application examples
draining turbines during start-up
draining boilers, finned tubes, rotary cylinders and laundry machines
