thermo-ag尊龙凯时
issue date：2016/10/13 rifox steam traps page views：1720
application
draining pipes
draining heat tracings
function
a special liquid inside the capsule evaporates and condenses due to changes in temperature
rising temperature closes, decreasing temperature opens the outlet
design features
depending on the capsule type lower or stronger condensate under cooling
lower under cooling prevents from condensate back-up
venting
automatic start-up and continuous venting when used as trap
additional equipment
non return valve
steam lock release nozzle
application examples
draining pipes, heat tracings, steam distributors and smaller heat consumers
ideal for venting pipe systems
ideal for venting steam chambers
