application
draining compressed air and pressurized gas systems
steam spaces without rock bottom for draining
function
thermodynamic steam traps are draining steam condensate intermittently by using thermal and fluidic properties
design features
small and compact
adjusts itself to the operating conditions
discharged condensate has very small under cooling
robust valve design
insensitive to water hammers and frost
design gasket free, metal-seated
valve also acts as return flow lock
application examples
draining vulcanizing machines
rotary cylinders
heat tracings
steam pipes
draining boilers, finned tubes and laundry machines
